This Q&A is from a NSW lot owner who is concerned about storage cages blocking the car park ventilation. The query has been answered by Christine Byrne from Green Strata, Tracey Wyber from Trackie Industries and Andrew Terrell from Bright & Duggan.
Question: A lot owner’s storage cages partially block the car park exhaust vents, effectively changing the designed of the car park ventilation. Can the Owners Corporation insist this is removed?
GET THE LATEST STRATA NEWS / ARTICLES DIRECT TO YOUR INBOX HERE
A lot owner in our strata of 5 lots has built 2 cages in the shared garage.
Their parking spaces are on title however the storage cages and their contents partially block the car park exhaust vents in the ceiling of the parking garage which discharge through concrete vents in the common property yard. This effectively changes the designed of the car park ventilation.
Can the owners corporation insist the obstructing storage cages be removed?
Who is liable if there’s an exhaust event in the garage?
Answer: The construction might be illegal and removal can be insisted by the owners corporation.
Tracey: Our experience has been that you can insist that anything compromising air flow be removed. Ventilation and air flow must be in accordance AS 1668.2.
Tracey WyberTrackie Industries
E: tracey@trackieind.com.au
Andrew: Was the construction of the cages subject of a by-law and general meeting approval? If not, the construction might be illegal and removal can be insisted by the owners corporation.
Whether the owners corporation can insist they be removed will be subject to whether approval was given by the owners corporation in the first place.
Ideally (even if approval was provided), the committee would meet with the owner to negotiate on the issue. In similar circumstances, I have seen this resolved by ensuring that items are only stored within a certain height within the cage and that a by-law stipulates a right of access by the owners corporation for the purpose of maintaining fire control/ventilation.
Andrew TerrellBright & Duggan
E: Andrew.Terrell@bright-duggan.com.au
Carpark Ventilation
Carparks that are not adequately naturally ventilated must be mechanically ventilated.
Ventilation systems usually consist of exhaust and supply fans with large power ratings.
Many carpark ventilation systems are either running at full speed, are turned off, or operating on timers during perceived “peak periods”. The first approach imposes a significant energy cost and the latter two can compromise occupant health and safety.
Relevant Standards for Carpark Ventilation Systems
The primary requirements are:
Carpark ventilation systems must operate at all times unless they are automatically controlled by a carbon monoxide (CO) monitoring system
The system must also provide at least 1 air change in every 24 hr period
The levels of CO that will trigger operation of the system vary depending on whether the carpark is occupied or not. For example, if a building manager’s office is located in the carpark, the system will trigger at a lower CO concentration level
If the system has automated controls, carpark ventilation rates can vary depending on the concentration of CO detected (see Variable Speed Operation below)
No point in the car park can be more than 25m away from a sensor
Additional energy saving measures are permitted for small car parks – 40 or fewer car spaces (see Small car parks section below)
The systems must be serviced twice-yearly
There are some variations in the standards that are best interpreted and assessed by a qualified service provider.
Variable Speed Operation
Since car park fans are very power hungry, variable speed drives can make a significant difference to the power consumed. The standards provide for the fans to operate at different speeds, depending on the level of CO detected by the sensors.
Ventilation rates vary according to the concentration of CO detected in relation to the system’s configured CO exposure limit (EL) – the concentration of CO that triggers fan operation:
At 75% of the EL and above, the system runs at the full ventilation rate
Between 50% and 75% of the EL, the system operates at a variable ventilation rate as defined in the standard
Below 50% of the EL, the system can operate at 25% of full ventilation rate
Below 25% of EL, intermittent ventilation is allowed
The system can turn off below 15% of EL and restart again at 25% of full ventilation rate when 25% of EL is reached
NOTE: There is a cubic relationship between fan speed and power consumption i.e. if the fan speed doubles, power consumption increases 8-fold, and vice-versa.
Small Car Parks
For car parks with 40 or fewer car spaces, energy saving measures additional to a variable speed operation are allowed.
The airflow rate can be halved if all vehicles remain parked and engines don’t operate for more than 2 hours. If the car park is also unoccupied at the same time, the system can be shut down. The system can be reactivated by motion detectors in doorways and lift doors and whenever vehicle entrance doors are opened.
Potential Cost Savings from the Right Carpark Ventilation
Decreased operational costs through reduced energy consumption – any reduction in speed results in significant energy savings
Peak Demand cost savings – installing VSDs reduces peak demand by removing the high surge currents of power associated with starting fans at full speed
Maintenance cost savings – a softer start at lower speeds reduces wear and tear on the equipment
